The new SONEL MPI-516 Multifunction Electrical Installation Tester is coming soon!

We are currently waiting for confirmed delivery dates and working hard to offer the best possible pricing. Just a little more patience!

In the meantime, let's take a closer look at its technical features and capabilities.

Technical Specifications & Features

• Voltage and Frequency Measurement

• Fault Loop Impedance Measurement: 23 A test current at 230 V, with 0.01 Ω resolution and accuracy according to the applicable standard, over a range of 0.13 Ω to 1999 Ω.

• Fault Loop Impedance Measurement: 1 A test current, suitable for circuits protected by low-rated circuit breakers.

• Low-Current Fault Loop Impedance Measurement: Testing downstream of RCDs without tripping them.

• Insulation Resistance Measurement: Test voltages from 50 V to 1000 V, with 1 kΩ resolution.

• RCD Testing: Supports AC, A, F, B, and EV types, including comprehensive testing of EV charging stations.

• Continuity and Resistance Testing: Low-current continuity testing and resistance measurement with a 200 mA test current.

• Phase Sequence Testing

• Earth Resistance Measurement: 3-pole (3P) and 4-pole (4P) methods, including 15 m and 30 m test leads and two earth electrodes.

• Surge Protective Device (SPD) Testing – NEW!

• Insulation Monitoring Device (IMD) Testing – NEW!

Design & Usability

The MPI-516 features a powerful rechargeable lithium battery, a large, clear color touchscreen, and an intuitive, user-friendly interface.

A Hebrew-language interface is also planned for a future release.

And the best part? It weighs just 1.5 kg!

Stay tuned for availability and pricing updates!
