DG992

The DG900 series generates frequencies up to 100 MHz, with 16-bit resolution and arbitrary waveforms of up to 16 Megapulses. SiFi II adds additional filtering capabilities, making this one of the most flexible generators on the market.

Rigol DG992 Characterized with 2 channel function / arbitrary waveform generator with 100 MHz bandwidth, 250 MSa/s and 16 Mpts memory.

• Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
• Maximum output frequency (Sine): 100MHz
• 16 Mpts memory depth per channel for arbitrary waveforms
• Standard dual-channel with the same performance, equivalent to two independent signal sources
• High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
• Built-in up to 8 orders harmonics generator
• Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
• Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
• Sample rate up to 250 MSa/s, vertical resolution 16 bits
• Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
• Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
• Standard waveform combine function, capable of outputting specified waveforms combined with the basic waveforms
• Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users’ configurations
• USB HOST&DEVICE interface (standard); USB-GPIB function supported
• 3” TFT color touch screen
• RS232, PRBS, and Dualtone outputs supported
