DG2072

Function Generator 70 MHz, 2 Ch

₪ 3,077.00 +VAT 3077.0 ILS ₪ 3,077.00

₪ 3,077.00 incl. VAT

Available on back-order

This combination does not exist.

Add to cart

Authorized importer and distributor, manufacturer warranty
Technical advice before and after purchase
New unit in the manufacturer’s original packaging

The DG2000 is a digital waveform generator with a frequency range of 100 MHz and 16-bit resolution. It can reproduce any waveform with high signal fidelity, and it offers additional filtering capabilities. Rigol DG2072 arbitrary waveform generator has 2 channels and a 70 MHz maximum bandwidth, 250 MSa/s sample rate and 16 Mpts memory capacity.

Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200ps
16 Mpts memory depth per channel for arbitrary waveforms
Standard dual-channel with the same performance, equivalent to two independent signal sources
High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
Built-in high-order harmonic generator (at most 8-order harmonics)
Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
Sample rate up to 250 MSa/s, vertical resolution 16 bits
Arbitrary waveform sequence editing function available; arbitrary
waveforms also can be generated through the PC software
Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
Standard waveform combine function, capable of outputting specified waveforms combined with the basic waveforms
Standard channel tracking function, when enabled, all the parameters of both channels are updated based on users' confi gurations
Standard interface: USB Host&Device and LAN (LXI Core 2011 Device);
USB-GPIB function supported
3'' TFT color touch screen
RS232, PRBS, and Dual-tone outputs supported
